名 称：排渣闸阀
型 号：PZ41H
口 径：50-600
压 力：1.0-6.4Mpa
材 质：铸铁、铸钢、不锈钢
厂 家：上海枚耶阀门有限公司
| PZ41H排渣闸阀部件材质： |
| 型号 | 材料 | |||||
| 阀体、阀盖 | 闸板 | 阀体密封圈 | 阀杆 | 垫片 | 填料 | |
| PZ41H-10 | 灰铸铁 | 灰铸铁镶铬不锈钢 | 灰铸铁镶铬不锈钢 | 铬不锈钢 | 橡胶石棉板 | 石棉石墨 |
| PZ41H-16 | ||||||
| PZ41H-10C | 碳素钢 | 碳素钢堆焊铁基合金 | 碳素钢堆焊铁基合金 | |||
| PZ41H-16C | ||||||
| PZ41H-25 | ||||||
| PZ41H-40 | ||||||
| PZ41H-63 | ||||||
| PZ41H技术参数： |
| PZ41H型PN10~PN63主要性能参数 | ||||
| 型号 | PN | 工作压力/MPa | 适用温度/℃ | 适用介质 |
| PZ41H-10 | 10 | 1.0 | ≤100 | 灰渣水混合物（灰水比1:1:5zui大粒度≤50mm） |
| PZ41H-16 | 16 | 1.6 | ||
| PZ41H-10C | 10 | 1.0 | ||
| PZ41H-16C | 16 | 1.6 | ||
| PZ41H-25 | 25 | 2.5 | ||
| PZ41H-40 | 40 | 4.0 | ||
| PZ41H-63 | 63 | 6.3 | ||
| PZ41H外形尺寸： |
| GB 1.6Mpa | |||||||||||
| DN | 50 | 80 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 |
| L | 250 | 280 | 300 | 350 | 400 | 450 | 500 | 550 | 600 | 650 | 700 |
| H | 335 | 510 | 685 | 790 | 885 | 1015 | 1190 | 1350 | 1460 | 1620 | 1800 |
| D0 | 250 | 280 | 300 | 300 | 350 | 400 | 450 | 500 | 500 | 550 | 550 |
| GB 2.5Mpa | |||||||||||
| DN | 50 | 80 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 |
| L | 250 | 280 | 300 | 350 | 400 | 450 | 500 | 550 | 600 | 650 | 700 |
| H | 335 | 510 | 685 | 790 | 885 | 1015 | 1190 | 1350 | 1460 | 1620 | 1800 |
| D0 | 250 | 280 | 300 | 300 | 350 | 400 | 450 | 500 | 500 | 550 | 550 |
